Hand Held or Portable Laser Marking Machine

We Give the Best Services

Hand Held or Portable Laser Marking Machine provide fast speed, permanent marking and it is able to code high-resolution logos for brand protection, barcodes or QR codes, as well as dates, batch codes and any other text. Hand Held or Portable Laser Marking Machine offers reliable and rapid product coding and marking for any production line. As a leading laser machine manufacturer, we at Dolphin Laser Machine provide the best quality Hand Held or Portable Laser Marking Machine all over India.

WHY YOU MUST BUY?

24X7 HOURS NON STOP WORKING

EASY TO OPERATE MACHINE

NO INK,NO CHEMICAL, NO GAS REQUIRE

NO NEED SKILL OPERATOR

PERFECT SOLUTION FOR SENSITIVE MACHINE

SAVE TIMES AND LAW LABOUR WORK

SAVE TIMES AND LAW LABOUR WORKS

WITHIN 2 SECOND YOUR BRAND PRINTING

WORKING ON SINGLE PHASE

ZERO MAINTENTENANCE

Technical Specifications Material Features Applications
Sr. No. Parameters Details
1 Laser Type Pulsed Fiber Laser
2 Laser Power 20 Watt (Optional 30,50)
3 Laser Life 1,00,000 + Hours + Tested Hour
4 Marking Area 100*100 mm (Optional 70*70, 100*100, 150*150, 200*200, 250*250, 300*300)
5 Marking Speed ≤ 10,000 mm per/ second
6 Operating Voltage 100-240V AC / 50-60 Hz
7 Electric Consumption < 500 W
8 Material Surface Flat & Round ( 2 in 1 Machine )
9 Marking Depth 0.001 to 4.00 mm (Depend on Materials)
10 Supporting Format PLT, DXF, AI, JPG, BMP, SVG, BOT, GBR, DST, NC, JPEG, GIF, PNG, TIF, TXT, DOCX, XLSX
11 Min Character Height 0.35 mm (Depend on Materials)
12 Min line width 0.03 mm (Depend on Materials)
13 Beam Quality M² < 2.0
14 Single pulse energy (mJ) 1 to 50 KHz
15 Repetition Frequency Range 20-100 KHz
16 Laser Class Class IV
17 Output power stability Continue Work 4 Hours < 2 %
18 Optical Noise < 2 % RMS
19 Wavelength 1064 ± 4 nm
20 Polarization Random
21 Power Adjustment 0 to 100%
22 Cooling System Air cooled
  • Mobile Accessories
  • Electronic Components
  • Cosmetic Industries
  • Sensitive material
  • Glass Engraving
  • Crystal Engraving
  • PCB Engraving
  • Semi-Conductor
  • Ceramic Engraving
  • Paper Board
  • Polymer Material
  • Coating Film
